Product Description
Rotator widely used in food, automation, chemical, materials recycling, smelting foundry industries, as well as any need to rotate the hopper or box tipping and mixing occasions, the goods can quickly flip or conversion, and then immediately coherent the fork back to its original location.
Features
Hydraulic system: hydraulic motor and foreign companies jointly developed by a new generation of products; rotating hinge and seal oil are imported products. Rotating two-way hydraulic oil circuit, self-locking, ensuring safety at work.
Structural parts: the slewing bearing slewing bearings with large modulus, the load capacity; worm and worm involute tooth profile, can improve efficiency, reduce heat loss, but also to achieve self-locking feature.
Mechanical performance: the case can be achieved with a 360 ° two-way rotation, a group of asphalt can be added to meet the requirements; standard fork can be used directly without modification.
Advantages
1. Proven durable construction design, unique rotating driven system, meet the high strength continuous operation.
2.Strong rotating driving torque achieved the stable and reliable rotating function.
3.Hydraulic motor fixed with reversible hydraulic lock, any angle position of lock function.

Specification

Catalogue Order No. Capacity @ Load Center Truck/Rotator Mounting Class Rotator/Forks
Mounting Class Carriage Width
(mm) Fork Max Spacing
(mm) Fork Min Spacing
(mm) Overall Width
(mm) Weight
(kg)
RRB20D-001A 1700@500 II II 815 705 610 840 188
RRB20D-002A 1600@500 II II 815 705 610 840 254
RRB20D-003A 1600@500 II II 815 705 610 840 259
RRB20D-004A 1600@500 II II 815 705 610 840 268
RRB20D-005A 1600@500 II II 815 705 610 840 277
RRB20D-006A 2200@500 II II 815 705 813 840 300
RRB20D-007A 2200@500 II II 940 835 813 965 309
RRB30D-008A 3000@500 II II 940 855 813 965 313
RRB30D-008B 3000@500 III II 940 855 813 965 329
RRB30D-009A 3000@500 II II 1145 1060 813 1170 327
RRB30D-009B 3000@500 III II 1145 1060 813 1170 343
RRB35D-010B 3500@500 III III 1065 990 813 1090 390
RRB35D-011B 3500@500 III III 1220 1140 813 1245 406

Note:Obtain the actual capacity of the forklift and attachments from the forklift manufacturer,One sets additional oil circuit required on forkliftAccording to user needs to increase forks. Please note the fork's capacity.The actual mount ,please according to the fork width adjustment positioning block, choose one mating surface, preventing load rotates, fork on the upper and lower cross beam under moving.Please contact the sales from LANDHONG.
Hydraulic Flow & Pressure

Model Min.Hydraulic Flow(L/min) Rec. Hydraulic Flow(L/min) Max.Hydraulic Flow(L/min) Rec. Hydraulic Pressure(Bar) Max. Hydraulic Pressure(Bar)
RRB20D 20 40 60 35 160
RRB30D 20 40 60 35 160
RRB35D 20 40 60 35 160
RRB35D 20 40 60 35 160

Rotator Specification

Model Rotator Speed Rotator Torque
RRB20D 7.0r/min@57L/min 7200N.M@160Bar
RRB30D 5.2r/min@57L/min 9000N.M@160Bar
RRB35D 5.2r/min@57L/min 9000N.M@160Bar
RRB35D 5.2r/min@57L/min 9000N.M@160Bar

Options
Forks
180 degrees rotator
Welding type of hook
