Technical parameters of plasma power supply:

Product Name plasma cleaner power supply
Items No. CY-AC10KV
Input Voltage AC220±10%V, AC110V
Output Power 0~500W
Output Current AC 100mA(max)
Output Voltage AC 10KV(max)
Response Time ≤1mS
Optocoupler Interface Control DC(5±2V) /Bright dipping
Laser power regulation 1. Regulate output current of the laser power supply by the potentiometer
2. Controlled by PWM (amplitude of TTL level)
Laser switch Button control or optocoupler interface control
Temperature -10~+40ºC
Humidity ≤85%
Cooling mode Air-cooling
Dimensions 280*225*113(mm)
Protective Open circuit protection, short circuit protection

Application:
Coating of the LCD screen, spraying and silk-screen of the shell, the buttons and other structural parts, removing glue, dirt and cleaning the surface of the PCB board and lens...
Removal dirt and clean before paste sealants of the automobile industry car lampshade, brake pad, door...
