Technical parameter of plasma power supply:

Items No. CY-P40L
Input Voltage AC380±10%V
Output Power 40KW
Output Current 0~48A
Output Voltage Work voltage 200~800V, no-load>1KV
Output Wave form Quasi-sine-wave
Output Mode Constant voltage / constant current / constant power
Regulation Precision ≤1%
Efficiency ≥90%
Power Factor cosΦ≥0.9
Communication Mode Analog / RS485 / RS232
Display Mode LED segment display
Output Protection Output overvoltage / output overcurrent / output offset
Input Protection Output overvoltage / output undervoltage / input overcurrent / open phase
Safety Protection Grounding protection / leakage protection / external control protection / lightning protection / overheating
Insulation Class B
Protect Grade IP20
Protection Response Time 1uS
Temperature 0~35ºC
Humidity ≤80%
Cooling mode 1~10kw air-cooled; 10kw~100kw water-cooled
Dimensions 480*263*550 (mm)
Net Weight 47.0kg
