Single tank ultrasonic cleaning machine cleaner for cleaning and degreasing and derusting of metal aluminum stamping parts

Product description of Ultrasonic cleaning machine
The ultrasonic cleaning machine is mainly composed of an ultrasonic signal generator transducer and a cleaning tank. The high-frequency oscillation signal of the ultrasonic signal generator is converted into a high-frequency mechanical oscillation of tens of thousands of times per second by the transducer, and ultrasonic waves are formed in the cleaning liquid (medium). It radiates forward in the cleaning liquid in the way of alternating high frequency of positive pressure and negative pressure, causing numerous tiny bubbles in the cleaning liquid to constantly generate and continuously burst, which is called the cavitation effect. When the bubble bursts, it can form an instantaneous high pressure of more than 1000 atmospheres, and produce a series of explosions to release huge energy, forming a huge impact on the surroundings, thus continuously impacting the surface of the workpiece, so that the dirt on the working surface and gap can be quickly peeled off to achieve the purpose of surface purification of the workpiece.

Technical parameters of Ultrasonic cleaning machine

Inner tank size (MM) 8000 * 1600 * 1600 Capacity 20480L
Skymen transducer 1512 pieces Ultrasonic power 0-75600W adjustable
frequency 28KHz / 40KHz optional Heating power 48000W
Total power 123600W Voltage 380V three-phase
temperature control Normal temperature -95ºC Time control 0-99 hours
Liner material 304 stainless steel Liner thickness 3MM
Water inlet and outlet Standard Universal wheel Standard
Certificate of conformity Standard Instructions Standard
Features Remove oil, remove rust, remove wax, remove glue, remove dust, remove ink, remove rosin solder, remove oxide scale, fingerprint, carbon deposit, etc.
Field of application Hardware molds, auto parts, aviation ships, coal and oil fields, circuit boards, electronic components, hydraulic parts, aluminum castings, precision hardware, optical lenses, etc.
